The Cotek SC2000-112 is a 2000 Watt pure sine wave inverter, 100 Amp
automatic multi-stage battery charger, and a 30 Amp AC transfer system,
all in one compact unit. It features advanced power electronics and
digital signal processor technology, and is designed for safe and
reliable use in mobile applications, such as RV's and boats, as well as
emergency backup and off-grid applications.
The SC2000-112
converts 12 volts DC to 2000 watts of clean, pure sine wave power, and
is capable of surging up to 4000 VA for 2 seconds, ensuring even the
most demanding motor driven loads, such as fans, pumps, and compressors,
are able to be started.
The Cotek SC2000-112 is equipped with an
adjustable 100 Amp automatic 3-Stage, PFC (Power Factor Corrected), and
PI (Proportional-Integral) multistage battery charger. The PFC feature
controls the amount of power used to charge the batteries to obtain a
power factor as close as possible to 1, while the PI feature allows the
charger voltage and current to change independently. These two features
maximize the real power available from the AC power source (i.e.,
utility or generator), which translates into less power wasted and
greater charging capabilities than most chargers today.
In addition to its standard inverter/charger function, the SC2000-112 features Power Sharing and Generator functions.
Power
Sharing allows the maximum level of AC pass through power to be
adjusted to ensure sufficient power is left over and available for
battery charging. The Power Sharing level can be adjusted from the
CR-20C remote.
If the load exceeds what the generator or shore
power can provide, the Generator function can increase the total
available AC power available by adding power from the inverter and
batteries to meet the needs of the load.
The Cotek SC2000-112 is CE and UL certified to UL458 and UL1741 for safety, is FCC approved, and carries a 2-year warranty.
If you find a lower advertised price on any Cotek product, give us a chance to match or beat it. In most cases we can! Call us at 1-800-367-3019 or e-mail us at [email protected].
| Inverter Specifications |
| | Input | | 12 VDC | | Output voltage | | 110 VAC, 60 Hz (user selectable) | | Continuous Power | | 2000 W (16.6 A) | | Surge Power (2 sec) | | 4000 VA (33.3 A) | | Output waveform | | Pure sine wave | | Transfer relay | | 30 Amp |
|
| | Charger Specifications |
| | Input | | 120 VAC, 60 Hz | | Output Current | | 25 / 50 / 75 / 100 ADC | | Output voltage | | 16.0 VDC maximum |
|
| | General Specifications |
| | Dimensions | | 17.8 x 9.9 x 4.6 in (453 x 251 x 116 mm) | | Inverter weight | | 13.2 lbs (6.0 kg) | | Shipping weight | | 15.0 lbs (6.8 kg) | | Warranty | | 2 years |
See spec sheets for additional info
|
|
|
 |
|
 |
|
|
|
 |
|
 |
|
Product Features- 2,000 watts continuous power output
- 4,000 watts surge capability
- 12 volt DC input
- Bi-directional all-in-one design
- Pure sine wave output for sensitive electronics and inductive loads
- Multistage 100A PFC and PI battery charger
- Compatible with AGM, Gel, Flooded, and LiFePO4 batteries
- Battery equalization function
- Temperature compensated charging
- Built-in 30 Amp transfer relay
- AC hardwire input and output
- DC output terminal (20A)
- LED status indicators
- Power generator function
- Power support function
- Power save mode
- Temperature and load controlled cooling fan
- UL458 & Supplement SA / CSA C22.2 No. 107.1-01
- UL1741 / CSA C22.2 No. 107.1-01 / KKK-A-1822F (For Ambulance)
- 2 year warranty
Protection Features- Low-voltage alarm (11.0 VDC)
- Low-voltage shutdown (10.5 VDC)
- Over-voltage alarm (15.5 VDC)
- Over-voltage shutdown (16.5 VDC)
- Over-current protection
- Overload shutdown
- Short-circuit protection
- Reverse polarity protection (internal fuse)
